ZALMAN WATTTERA (EBTII) 1200W 80 PLUS GOLD FULLY MODULAR PSU POWER SUPPLY
With the Zalman WattTera you can enjoy a fully modular PSU with 80 plus Gold certification. A fully modular design minimises resistance and voltage drop on the cables and lowers impendance to further enhance energy efficiecy. The PSU also features flat cables, unlike sleeved cables, flat cables make it easier to organise when building your system.
Key Features:
Full Modular PSU
Integrated advanced design method of Sense 6-pin to reduce voltage fluctuation to within 3%
All cables are flat, easy cable management
Up to 92% energy conversion efficiency
Active PFC with 99.9% Maximum Power Factor
Aluminium high Performance Solid Japanese Capacitor that Handles up to 221?F
Built-in EMI Filter for Noise Reduction
12V DC-to-DC Convertor with 99.43 Availability
Multiple Protection Circuit System
Highly Energy-Efficient Standby Power Supply, 0.5W (ErP Lot 6 Certified)
TECHNICAL SPECIFICATIONS
Model :WATTTERA (EBTII) 1200W
Efficiency: Max 91% @ 230 VAC, Typical Load
Dimensions :160 (L) x 150 (W) x 86 (H) mm
MTBF: 100,000 Hours
Weight: 3.48 kg
Operating Temperature: 0~40 ?
Type: Intel ATX 12V ver.2.31
Protection: OCP/ OVP/ OPP/ OTP/ UVP/ SCP
PFC Active: PFC(<0.9)
Regulatory :UL, FCC, CB, CE, KC, EAC, RoHS
Input Voltage: 115- 240 VAC
Input Current: 12-6A
Input Frequency: 50-60Hz
Fan Size: 135mm
Cables:
(Connector) Mainboard (Sense Connector 1ea) Cable X 1
EPS Cable X 2
PCI Express Cable X 8
IDE (Connector 3ea) + FDD (Connector 1ea) Cable X 1
S-ATA Cable X 3
Bearing :Two Ball Bearing
80 PLUS Gold
