Key Features
•Built in AVR
•DC Cold Start
•Audible Alarm
•USB Connectivity
•Intelligent CPU Control
•Wide Input Range
•Software Monitoring included (Serial # on CD Sleeve)
•Compatible with generators
•Strong EMI compatibility, no EMI to load
•Protection against Surge, Over / Under voltage
Specifications
Power: 720W
Noise: <45db (1 metre)
Temperature: 0 - 40°C
Humidity: 20% - 90% (Non-condensing)
Input - Phase: Single & GND
Input - Voltage Range: 165 - 275V
Input - Frequency: 50Hz ± 10%
Output - Voltage Range: 220V ± 10%
Output - Wave Form: Sine Wave (AC Mode) Square Wave (Inverter)
Output - Frequency: 50Hz ± 1% (Battery Mode)
Output - Crest Factor: 3:1
Output - Transfer Time: <= 6ms
Protection - Energy Rating: 320 Joules instantaneous response
Protection Test Standard: IEEE 587 Cat. A & B
Protection - LAN: RJ45 Surge protection
Noise Filtering - EMI / RFI: Full time suppression
Communication: USB
I/O Ports - UK Mains Socket: Three
I/O Ports - RJ45: Two (In / Out)
I/O Ports - USB: One (For USB Monitoring)
I/O Ports - IEC Socket: Three
Battery - Type: Sealed Lead-Acid, Maintenance Free
Battery - Quantity: 12V7AH x 2
Battery - Recharge Time: 90% capacity after 8 hours
Battery - Backup time: 15-20 minutes (dependent on load)
General Specifications
Manufacturer Part Number: PC 1200VA
EAN Number: 5055492403124
Has Mains Plug: Yes
Colour: Black
What's In The Box: UPS
USB Cable (A to B)
Software (UPSmart 2000R - Serial # on CD sleeve)
2 x UPS Fuse
Unit (Product) Dimensions (mm): 125mm x 230mm x 338mm (W x H x D)
Packaging Dimensions (mm): 386mm x 302mm x 186mm (W x H x D)
Net Weight (KGs): 10.7 KGs
Gross Weight (KGs): 11.4 KGs
