EK-AF (Adapter Fitting) is a revolvable angled (90°) adapter fitting with G1/4" threads.
Adapter allows connection of fitting with G1/4" threads to extend tubing possibilites in your water cooled system.
Specifications:
- Material: made of nickel plated brass
- Threads: G1/4" BSP; 4,5mm male thread length / G1/4" BSP, 6mm female thread length
- Outer diameter of a knurled part: 19,8mm
- Installed height: 28mm
- Sealed with high quality NBR oring.
ROHS compliant!
Please note:
- All AF Angled adapters are hand polished and rounded therefore minor geometrical imperfections are to be expected. This fact does not fall under warranty terms and RMA rights!
