SPECIFICATION:
CPU Intel® Socket LGA1700 for 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processorsx
Chipset Intel Z690
Memory Dual Channel DDR5 Memory Technology
- 4 x DDR5 DIMM Slots, 4800MHz, 128GB max
- Supports DDR5 non-ECC, un-buffered memory up 6400(OC)
Onboard Graphics Outputs 1x HDMI 2.1 with HDR port, supports a maximum resolution of 4K 60Hz
1x DisplayPort 1.4 port with HBR3, supports a maximum resolution of 4K 60Hz
PCI Slots 3x PCIe x16 slots
PCI_E1 & PCI_E2 slots (From CPU)
Support PCIe 5.0
Support x16/ x0, x8/ x8
PCI_E3 slot (From Z690 Chipset)
Supports PCIe 3.0 x4
Storage
4x SATA 6Gb/s ports - SATA5~8x (From Z690 Chipset)
2 x SATA 6Gb/s ports - SATAA & SATAB (From ASMedia ASM1061)
5x M.2 slots (Key M)
M2_1 slot (From CPU)
Supports PCIe 4.0 x4
Supports 2260/ 2280/ 22110 storage devices
M2_2 slot (From Z690 Chipset)
Supports PCIe 4.0 x4
Supports 2260/ 2280 storage devices
M2_3 slot (From Z690 Chipset)
Supports PCIe 4.0 x4
Supports 2242/ 2260/ 2280/ 22110 storage devices
M2_4 slot (From Z690 Chipset)
Supports PCIe 3.0 x4
Supports SATA 6Gb/s
Supports 2242/ 2260/ 2280 storage devices
M2_5 slot (From Z690 Chipset)
Supports PCIe 4.0 x4
Supports SATA 6Gb/s
Supports 2260/ 2280 storage devices
Networking Intel® I225V 2.5Gbps LAN controller
Intel® Wi-Fi 6E module - Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/6GHz up to 2.4Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax
Supports Bluetooth 5.2
Audio Realtek® ALC4080 Codec - 7.1-Channel High Definition Audio
Connectivity Intel® Z690 Chipset
1x USB3.2 Gen2x2 20Gbps Type-C port on the back panel
6x USB 3.2 Gen 2 10Gbps ports (5 Type-A ports on the back panel, 1 Type-C available through the internal connector)
2x USB 3.2 Gen 1 5Gbps ports available through the internal connector
4 USB 2.0 ports on the back panel
USB Hub-GL850G
4x USB 2.0 ports available through internal connectors
Internal Ports 1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
1 x CPU fan h
