Supports 9th / 8th Gen Intel® Core™ / Pentium® Gold / Celeron® processors for LGA 1151 socket
Supports DDR4 Memory, up to 2666 MHz
Intel Gaming LAN: Premium network solution from Intel® for professional and
multimedia use. Delivers a secure, stable and fast network connection
Pre-installed I/O Shielding: Better EMI protection and more convenience for installation
Set Core Power Free: Extended Heatsink Design, Core Boost, DDR4 Boost
Turbo M.2: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs.
Mystic Light Extension: Control both RGB and RAINBOW strips with independent LEDs added to your system with Mystic Light APP and mobile device
Dragon Center: A brand new software which integrates all MSI tools like GAME MODE, VOICE BOOST, LIVE UPDATE with user friendly user interface.
CPU Support
Supports 8th Gen Intel® CoreTM, Pentium®
Gold and Celeron® Processors for Socket
LGA1151
Chipset
Intel® B365 Chipset
Memory Support
4x DDR4 memory slots supporting up 64GB
Supports DDR4-2666 Memory (Max)
Support Dual-Channel mode
Support non-ECC, un-buffered memory
Supports Intel® Extreme Memory Profile
(XMP)
* Please refer www.msi.com for more
information on compatible memory
Expansion Slots
1x PCIe 3.0 x16 slot (From CPU)
2x PCIe 3.0 x1 slots (From PCH)
Onboard Graphics
1x HDMI™ port, supports a maximum
resolution of 4096x2160@30Hz
Storage
Intel® B365 Chipset
6x SATA 6Gb/s ports
1x M.2 port, supports PCIe 3.0 x4 and SATA
6Gb/s standards, 4.2cm/ 6cm/ 8cm/ 11cm
length SSD cards.
SATA1 port will be unavailable when
installing the M.2 SATA module in M.2 slot.
Supports Intel® Rapid Storage Technology
Intel® OptaneTM Memory Ready Intel® B365
Express Chipset
USB
Intel® B365 Chipset
6x USB 3.1 Gen1 (4 ports on the back
panel, 2 ports available through the
internal USB connectors)
6x USB 2.0 ports (2 ports
