Gigabyte GeForce GTX 1050 Ti OC Low Profile 4GB GDDR5 Graphics Cards Product Description
Low Profile Design
•Low profile design with 167mm card length saves more spaces and fits slim or smaller system.
One-click Super overclocking
•With a simple click on XTREME engine utility, gamers can easily tune the card to meet their various gaming requirements without any overclocking knowledge, while saving the hassle of manual adjustment.
Flexible Connectivity
•Equip with one Dual-link DVI-D, one DP, and two HDMI ports and support up to 4 displays.
Ultra Cooling
•Lower RDS(on) MOSFETs are specially designed to produce lower switching resistance for faster electric current charging and discharging at extremely low temperature.
Low Power Loss
•Metal Choke hold energy much longer than common iron-core chokes at high frequency, thus effectively reduce core energy loss and EMI interference.
Longer Life
•Lower ESR Solid Capacitors ensure better electronic conductivity for excellent system performance and longer lifespan.
Intuitive XTREME Engine Utility
•Clock speeds, voltage, fan performance, and power target can be monitored and tuned in real-time according to your own preference through this intuitive interface.
Specification
Graphics Processing •GeForce® GTX 1050 Ti
Core Clock •Boost: 1442 MHz/ Base: 1328 MHz in OC Mode
•Boost: 1417 MHz/ Base: 1303 MHz in Gaming Mode
Memory Clock •7008 MHz
Memory Size •4 GB
Memory Type •GDDR5
Memory Bus •128 bit
Card Bus •PCI-E 3.0 x 16
Output •Dual-link DVI-D *1
•HDMI-2.0b*2 (Max Resolution: 4096x2160 @60 Hz)
•Display Port-1.4 *1 (Max Resolution: 7680x4320 @60 Hz)
•Digital max resolution 7680x4320
Multi-view •4
Card size •H=37 L=167 W=68.9 mm
PCB Form •Low Profile
DirectX •12
OpenGL •4.5
Recommended PSU •300W
Power Connectors •N/A
