X570-A PRO (AMD AM4) DDR4 X570 CHIPSET MOTHERBOARD
- Supports 2nd and 3rd Gen AMD Ryzen™ / Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics Desktop Processors for AM4 socket
- Supports 4 DIMMs, Dual Channel Memory DDR4, up to 4400+(OC) MHz
- Lightning Gen 4 Solution: The latest Gen4 PCI-E and M.2 solution with up to 64GB/s bandwidth for maximum transfer speed and performance.
- Frozr Heatsink Design : Designed with the patented fan and double ball bearings to provide best performance for enthusiast gamers and prosumers.
- Set Core Power Free: Core Boost, 8+4 pin CPU power connectors, DDR4 Boost
- Audio Boost 4: Reward your ears with studio grade sound quality.
- Multi-GPU: With Steel armor PCI-E slots. Supports 2-Way AMD Crossfire™
- AMD Turbo USB 3.2 Gen2: Powered by AMD USB 3.2 Gen2 controller, ensures an uninterrupted connection with more stability and fastest USB speeds
SOCKET - AM4
CPU (MAX SUPPORT) - RYZEN 9
CHIPSET - AMD® X570 Chipset
DDR4 MEMORY - 1866/ 2133/ 2400/ 2667/ 2800/2933 /3000 /3066 /3200 /3466 /3600 /3733 /3866 /4000 /4133 /4266 /4400 + Mhz by JEDEC and A-XMP OC MODE
MAX MEMORY (GB) - 128
PCI-E X16 - 2
PCI-E X1 - 3
SATAIII - 6
M.2 SLOT - 2
RAID - 0/1/10
LAN - 1x Realtek® 8111H Gigabit LAN Controller
USB 3.2 PORTS (FRONT) - 4(Gen1, Type A)
USB 3.2 PORTS (REAR) - 4(Gen1, Type A), 1(Gen2, Type A), 1(Gen2, Type C)
USB 2.0 PORTS (FRONT) - 4
USB 2.0 PORTS (REAR) - 2
AUDIO PORTS (REAR) - 5+ Optical S/PDIF (Realtek® ALC1220 Codec)
HDMI - 1
FORM FACTOR - ATX
