GIGABYTE A520M H MOTHERBOARD
Meet the A520M H motherboard by Gigabyte. Featuring Pure Digital VRM Solution, GIGABYTE Gaming LAN with Bandwidth Management, PCIe 3.0 x4 M.2, RGB FUSION 2.0, Smart Fan 5 and more. Supports 3rd Gen AMD Ryzen Processors, and features an anti-sulfur resistors design.
CONNECTIVITY
Maximise your systems potential thanks to the focus on M.2 technology. Enjoy high speed Gigabit LAN with automatic bandwidth allocation. Realtek 8118 LAN is a high performance and friendly network chip for gaming players with automatic bandwidth allocation to ensure the highest network priority of the game or application. Enjoy the most comprehensive features and the fastest and smoothest Internet experience.
PERFORMANCE
Enjoy epic performance thanks to the use of a 4+3 phases pure digital PWM + Low RDS(on) MOSFETs design to support the 3rd Gen AMD Ryzen CPUs by offering incredible precision in delivering power to the motherboard's most power-hungry components as well as delivering enhanced system performance and ultimate hardware scalability.
SMART FAN 5
Rest assured your PC will stay cool when the gaming heats up thanks to Smart Fan 5. Smart Fan 5 allows users to interchange their fan headers to reflect different thermal sensors. With Smart Fan 5, more hybrid fan headers that support both PWM and Voltage mode fans have been introduced to make the motherboard more liquid cooling friendly.
FULL TECHNICAL SPEFICATIONS
CPU
AMD Socket AM4, support for: 3rd Generation AMD Ryzen™ processors/ 3rd Generation AMD Ryzen™ with Radeon™ Graphics processors
(Please refer "CPU Support List" for more information.)
Chipset
AMD A520
Memory
2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory
3rd Gen AMD Ryzen™ Processors:
Support for DDR4 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules
3rd Gen AMD Ryzen™ with Radeon™
