- GREEN IS THE NEW GOLD
The EVGA SuperNOVA G5 joins the elite ranks of the EVGA 80 PLUS Gold power supplies. As the successor to the award-winning G3 series, the G5 power supplies continue to push the envelope with the latest certifications and Intel power-on standards. Starting with 80 PLUS Gold certification, fully-modular cable design, 100% Japanese capacitors, and an ultra-quiet 135mm Fluid Dynamic bearing fan with EVGA ECO mode, these power supplies are built for performance and silence. The EVGA G5 Series also includes a full suit of protections (OCP, OVP, UVP, OPP, SCP, OTP) for safety and security, and are covered by EVGA's industry-leading 10 year Warranty and Customer Support.
- GOLD RATED EFFICIENCY
80 Plus certification ensures your power supply isn't wasting power and turning it into excess heat. Under typical load, this power supply is 91% efficient or higher
ATX Cable 1x 600mm (m)
EPS Cable 2x 700mm (m)
PCIe Cable 2x 700mm, 2x 700mm, 850mm (m)
SATA Cable 3x 550mm, 650mm, 750mm (m)
Four-Pin Peripheral Cable 1x 550mm, 650mm, 750mm, 850mm (m)
Floppy Adapter 1x 100mm
AC Power 1x 1500mm (m)
Modular Cable Type Full
CONNECTOR QUANTITY
24 Pin ATX 1x 24pin (20+4)
EPS (CPU) 2x 8pin (4+4)
PCIe 6x 8pin (6+2)
SATA 9x
Four-Pin Peripheral 4x
Floppy 1x
POWER SPECS
AC Input 100 - 240 VAC, 12-5A, 50/60 Hz
Rail +3.3V +5V +12V +5Vsb -12V
Max Output 24A 24A 70.8A 3A 0.5A
849.2W
120W 849.2W 15W 6W
Total 850W @ +50C
